744060 14-Stage Binary Ripple Counter IC – 74HC4060

Add to wishlist

Product Details

  • Product: 14-Stage Binary Ripple Counter IC
  • IC number: 744060
  • No of pins: 16
  • Package: PDIP-16
  • Mounting type: through hole
  • Package contains: 1 x 744060 14-Stage Binary Ripple Counter IC

₹35.00 (ex. GST)

Add to wishlist

Features

  • Wide operating conditions
  • Output can drive up to 10 LSTTL loads
  • Low power consumption

Specification

  • Operating voltage range: 2V to 6V
  • Supply voltage (Vcc): -0.5V to +7.0V
  • Input voltage (Vin): -1.5V to Vcc + 1.5V
  • Clamp diode current: ±20mA
  • DC output current (per pin): ±25mA
  • Dc Vcc and GND current (per pin): ±50mA
  • Power dissipation: 600mW
  • Typical propagation delay: 16s
  • Maximum Quiescent current: 1 µA
  • Output drive capability: 10 LSTTL Loads
  • Operating temperature: Operating temperature: -55℃ to 125℃
